Vacuum cleaner motor -
XWBT95
Category: Vacuum cleaner motor
Model：XWBT95
Voltage：D24/D36
Noise (dBA)：≤87.5/≤91
Application：Brushed vacuum cleaner motor
Voltage：D24/D36
Noise (dBA)：≤87.5/≤91
Application：Brushed vacuum cleaner motor
| Rating Voltage（V） | D24 | D36 |
| Rating Frequency (Hz) | / | / |
| Rating Input Power (W) | 150-450 | 150-600 |
| Insulation Grade | Class A、E、B、F | Class A、E、B、F |
| Spark Grade | ≤2级 | ≤2级 |
| Vibretion（mm/s） | 15 | 15 |
| Life（A pair of carbon brush） | 300小时 | 300小时 |
XWBT95 Seroes Typical Motor Technic Parameter:
| Motor Type | XWBT9538-D24-450 | XWBT9538-D36-600 |
| Rating Voltage（V） | D24 | D36 |
| Rating Frequency（Hz） | / | / |
| Rating Input Power（W） | 450 | 600 |
| Maximal Airflow（M3/min） | 1.8 | 2.05 |
| Maximal Suction（Kpa） | 13.25 | 18.5 |
| Maximal Air Power（W） | 105.5 | 162 |
| Maximal Efficiency（%） | 22% | 27% |
| Noise（IM）（dBA） | ≤87.5 | ≤91 |
