Vacuum cleaner motor
NACE
PRODUCT CENTER
Vacuum cleaner motor -
XWHT95系列
Category: Vacuum cleaner motor
Model：XWHT9538-24-450
Voltage：DC24/DC36
Noise (dBA)：≤86/≤89
Application：Brushed vacuum cleaner motor
Voltage：DC24/DC36
Noise (dBA)：≤86/≤89
Application：Brushed vacuum cleaner motor
| Rating Voltage（V） | DC24 | DC36 |
| Rating Frequency (Hz) | / | / |
| Rating Input Power (W) | 150-450 | 150-650 |
| Insulation Grade | Class A、E、B、F | Class A、E、B、F |
| Spark Grade | ≤2 Class | ≤2 Class |
| Vibretion（mm/s） | 15 | 15 |
| Life（A pair of carbon brush） | ≥300 | ≥300 |
XWHT95 Seroes Typical Motor Technic Parameter:
| Motor Type | XWHT9538-24-450 | XWHT9538-24-450 |
| Rating Voltage（V） | DC24 | DC36 |
| Rating Frequency（Hz） | / | / |
| Rating Input Power（W） | 450 | 600 |
| Maximal Airflow（M3/min） | 1.7 | 2.0 |
| Maximal Suction（Kpa） | 14.0 | 19.0 |
| Maximal Air Power（W） | 103 | 160 |
| Maximal Efficiency（%） | 23% | 26% |
| Noise（IM）（dBA） | ≤86 | ≤89 |
